Aiguille industrielle · UY 118 GAS

UY 118 GAS FFG Chromium

UY 118 GAS FFG Chromium
SystèmeUY 118 GAS
PointeFFG
FinitionChromium
Tailles4

Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Special(s): Shank notch Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear

Tailles disponibles

Taille (Nm)RéférenceLongueur totaleConditionnementPoids
65/9 763582 41.1 mm 100 pièces 0.713 g
70/10 763572 41.1 mm 100 pièces 0.725 g
75/11 754892 41.1 mm 100 pièces 0.733 g
80/12 755272 41.1 mm 100 pièces 0.736 g

Caractéristiques techniques

Shank diameter1.5 mm
Length butt to eye36.6 mm
Overall length41.1 mm
Shank length16.5 mm
CoatingChromium
Needle formB
Needle form descriptionB1 – Straight needle with double groove and scarf
Canu pointSES
Canu designation24:08
Catalog designation366150BC01FFG
Further point designationsSES
Further point designations 02L BALL
Further point designations 03J BALL
Further point designations 04SIN
Further point designations 05NYR
Further point designations 06BPL
Further point designations 07TB
Further point designations 08B
Further point designations 09R K
Technical sewing applicationFlat seams
Stitch type class600
Special(s)Shank notch
Recommended forFine knitwear, Woven fabrics
Examples of useShirts, Blouses, Underwear
Point styleFFG - Cloth point
Needle systemUY 118 GAS
Needle system familyUY 118
VariantGAS
Pack standardN-S-00017 – Standard Packaging
Customary needle designationsFLX 118 A J
System designation 2SY 7060
Needle recommendationQuality choice
