Aiguille industrielle · UY 118 GKS
UY 118 GKS RG Chromium
UY 118 GKS
RG
Chromium
6
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Special(s): Shank notch Recommended for: Fine knitwear, Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 60/8 | 761422 | 41.1 mm | 100 pièces | 0.707 g |
| 65/9 | 759702 | 41.1 mm | 100 pièces | 0.69 g |
| 70/10 | 746482 | 41.1 mm | 100 pièces | 0.718 g |
| 75/11 | 704052 | 41.1 mm | 100 pièces | 0.721 g |
| 80/12 | 704062 | 41.1 mm | 100 pièces | 0.734 g |
| 90/14 | 758172 | 41.1 mm | 100 pièces | 0.747 g |
Caractéristiques techniques
| Shank diameter | 1.5 mm |
|---|---|
| Length butt to eye | 36.6 mm |
| Overall length | 41.1 mm |
| Shank length | 16.5 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Canu designation | 24:10 |
| Catalog designation | 366150BC02RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Flat seams |
| Stitch type class | 600 |
| Special(s) | Shank notch |
| Point style | RG - Cloth point |
| Needle system | UY 118 GKS |
| Needle system family | UY 118 |
| Variant | GKS |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | FLX 118 GCS |
| System designation 2 | SY 7062 |
