Aiguille industrielle · UY 121 GBS
UY 121 GBS FFG Chromium
UY 121 GBS
FFG
Chromium
5
Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 65/9 | 704332 | 43.9 mm | 100 pièces | 0.877 g |
| 70/10 | 704342 | — | 100 pièces | 0.887 g |
| 75/11 | 704352 | 43.9 mm | 100 pièces | 0.888 g |
| 80/12 | 704362 | — | 100 pièces | 0.903 g |
| 90/14 | 704372 | — | 100 pièces | 0.744 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | SES |
| Canu designation | 38:43 |
| Catalog designation | 389200AC03FFG |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Technical sewing application | Double chain stitch, Cover chain stitch |
| Stitch type class | 400, 600 |
| Point style | FFG - Cloth point |
| Needle system | UY 121 GBS |
| Needle system family | UY 121 |
| Variant | GBS |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | UYX 121 GBS |
| System designation 2 | MY 1046 |
| System designation 3 | SY 7283 |
