Aiguille industrielle · UY 121 GS
UY 121 GS RG Chromium
UY 121 GS
RG
Chromium
5
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 65/9 | 774482 | 43.9 mm | 100 pièces | 0.85 g |
| 70/10 | 776002 | 43.9 mm | 100 pièces | 0.885 g |
| 75/11 | 774492 | 43.9 mm | 100 pièces | 0.864 g |
| 80/12 | 704602 | — | 100 pièces | 0.69 g |
| 90/14 | 774502 | 43.9 mm | 100 pièces | 0.894 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B – Straight needle with double groove |
| Canu point | R |
| Canu designation | 36:05 |
| Catalog designation | 389200BC26RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Double chain stitch, Cover chain stitch |
| Stitch type class | 400, 600 |
| Point style | RG - Cloth point |
| Needle system | UY 121 GS |
| Needle system family | UY 121 |
| Variant | GS |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | 62X21 |
| System designation 2 | MY 1001 |
| System designation 3 | UYX 121 |
| System designation 4 | 3001 |
| System designation 5 | SY 3506 |
| System designation 6 | SY 7279 |
