Aiguille industrielle · UY 128 GAS
UY 128 GAS RG Chromium
UY 128 GAS
RG
Chromium
15
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 60/8 | 756482 | 44.6 mm | 100 pièces | 0.863 g |
| 65/9 | 781652 | 44.6 mm | 100 pièces | 0.869 g |
| 70/10 | 781662 | 44.6 mm | 100 pièces | 0.88 g |
| 75/11 | 781672 | 44.6 mm | 100 pièces | 0.89 g |
| 80/12 | 704922 | 44.6 mm | 100 pièces | 0.911 g |
| 85/13 | 759492 | 44.6 mm | 100 pièces | 0.907 g |
| 100/16 | 704942 | 44.6 mm | 100 pièces | 0.923 g |
| 110/18 | 704952 | 44.6 mm | 100 pièces | 0.766 g |
| 120/19 | 704962 | 44.6 mm | 100 pièces | 0.975 g |
| 125/20 | 704972 | 44.6 mm | 100 pièces | 0.985 g |
| 130/21 | 752372 | 44.6 mm | 100 pièces | 1.005 g |
| 140/22 | 704992 | 44.6 mm | 100 pièces | 1.032 g |
| 150/ | 705002 | 44.6 mm | 100 pièces | 0.888 g |
| 160/23 | 705012 | 45.2 mm | 100 pièces | 1.227 g |
| 170/ | 705022 | 45.2 mm | 100 pièces | 1.149 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Shank length | 14.5 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Canu designation | 38:00 |
| Catalog designation | 389200BC01RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Double chain stitch, Cover chain stitch |
| Stitch type class | 400, 600 |
| Point style | RG - Cloth point |
| Needle system | UY 128 GAS |
| Needle system family | UY 128 |
| Customary needle designations | TVX3 |
| System designation 2 | DVXG9 |
| System designation 3 | UY 124 GS |
| System designation 4 | 149X3 |
| System designation 5 | MY 1044 |
| System designation 6 | 1280 |
| System designation 7 | SY 3650 |
| Needle recommendation | Quality choice |
