Aiguille industrielle · UY 128 GAS
UY 128 GAS RG GEBEDUR™
UY 128 GAS
RG
GEBEDUR™
8
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating GEBEDUR™ Needle with titanium nitride coating for increased wear resistance. Its surface has a higher hardness compared to standard needles. This provides better protection against wear and abrasion, especially in the point and eye areas of the needle. Recommended for: Fine knitwear, Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 65/9 | 781972 | 44.6 mm | 100 pièces | 0.869 g |
| 70/10 | 781722 | 44.6 mm | 100 pièces | 0.88 g |
| 75/11 | 781732 | 44.6 mm | 100 pièces | 0.89 g |
| 90/14 | 763045 | 44.6 mm | 100 pièces | 0.923 g |
| 100/16 | 763052 | 44.6 mm | 100 pièces | 0.742 g |
| 110/18 | 760662 | 44.6 mm | 100 pièces | 0.947 g |
| 125/20 | 760672 | 44.6 mm | 100 pièces | 0.985 g |
| 140/22 | 760682 | 44.6 mm | 100 pièces | 1.042 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Overall length | 44.6 mm |
| Coating | GEBEDUR™ |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu designation | 38:00 |
| Catalog designation | 389200BD01RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Double chain stitch, Cover chain stitch |
| Stitch type class | 400, 600 |
| Point style | RG - Cloth point |
| Needle system | UY 128 GAS |
| Needle system family | UY 128 |
| Customary needle designations | UY 128 GBS |
| System designation 2 | TVX3 |
| System designation 3 | 149X3 |
| System designation 4 | 149X31 |
| System designation 5 | 1280 |
