Aiguille industrielle · UY 130 GHS
UY 130 GHS FFG Chromium
UY 130 GHS
FFG
Chromium
5
Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Medium-weight knitwear and woven fabrics Examples of use: Jeans, Workwear, Sweatshirts, Covers for mattresses, Seat covers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 90/14 | 705502 | — | 100 pièces | 0.781 g |
| 100/16 | 705512 | 45.6 mm | 100 pièces | 0.8 g |
| 110/18 | 705522 | 45.6 mm | 100 pièces | 0.986 g |
| 125/20 | 705532 | 45.6 mm | 100 pièces | 1.032 g |
| 140/22 | 705542 | 45.6 mm | 100 pièces | 1.215 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | SES |
| Canu designation | 39:62 |
| Catalog designation | 389200BC11FFG |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Technical sewing application | Double chain stitch |
| Stitch type class | 400 |
| Point style | FFG - Cloth point |
| Needle system | UY 130 GHS |
| Needle system family | UY 130 |
| Variant | GHS |
| Customary needle designations | UYX 130 GHS |
| System designation 2 | DVX47 J |
| System designation 3 | SY 7299 |
