Aiguille industrielle · UY 143 GS KSP
UY 143 GS KSP SD Chromium
UY 143 GS KSP
SD
Chromium
1
Point style SD - Cutting point Round point with polished triple cutting edges at the very end of the point • Slightly triangular cut in leather • Straight seam • Thread slightly elevated • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Recommended for: Paper, Woven material with polypropylene Examples of use: Feed bags, Transport bags, Nets
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 230/26 | 756632 | — | 50 pièces | 1.474 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Needle size Asia | 26 |
| Length butt to eye | 42.1 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | S |
| Canu designation | 45:27 |
| Catalog designation | 421200BC02S |
| Further point designations | R-TRI |
| Further point designations 02 | SD 1 |
| Further point designations 03 | TRI FACET |
| Further point designations 04 | TRI TIP |
| Technical sewing application | Bag closing |
| Stitch type class | 400 |
| Recommended for | Paper, Woven material with polypropylene |
| Examples of use | Feed bags, Transport bags, Nets |
| Needle size | 230 Nm |
| Point style | SD - Cutting point |
| Needle system | UY 143 GS KSP |
| Needle system family | UY 143 |
| Variant | GS KSP |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | UY 143 GS |
