Aiguille industrielle · UY 144 GS
UY 144 GS R Chromium
UY 144 GS
R
Chromium
1
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Paper, Woven material with polypropylene Examples of use: Feed bags, Transport bags, Nets
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 200/25 | 705952 | 47.3 mm | 100 pièces | 1.293 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Needle size Asia | 25 |
| Length butt to eye | 42.1 mm |
| Overall length | 47.3 mm |
| Shank length | 14.5 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Catalog designation | 421200BC03R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Bag closing |
| Stitch type class | 400 |
| Recommended for | Paper, Woven material with polypropylene |
| Examples of use | Feed bags, Transport bags, Nets |
| Needle size | 200 Nm |
| Point style | R - Cloth point |
| Needle system | UY 144 GS |
| Needle system family | UY 144 |
| Pack standard | N-S-00870 – Packaging 45 |
| Customary needle designations | UY 144 G |
