Aiguille industrielle · UY 147 GS
UY 147 GS R Chromium
UY 147 GS
R
Chromium
6
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics Examples of use: Jeans, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 90/14 | 705962 | 48 mm | 100 pièces | 0.797 g |
| 100/16 | 705972 | 48 mm | 100 pièces | 0.914 g |
| 110/18 | 705982 | — | 100 pièces | 1.084 g |
| 125/20 | 706002 | 48 mm | 100 pièces | 1.153 g |
| 140/22 | 706012 | — | 100 pièces | 0.953 g |
| 170/ | 706032 | 48 mm | 100 pièces | 1.285 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 42.7 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Canu designation | 45:43 |
| Catalog designation | 427200BC01R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Bag closing |
| Stitch type class | 400 |
| Recommended for | Woven fabrics |
| Examples of use | Jeans, Trousers |
| Point style | R - Cloth point |
| Needle system | UY 147 GS |
| Needle system family | UY 147 |
| Variant | GS |
| Customary needle designations | UOX 147 GA |
| System designation 2 | SY 7475 |
