Aiguille industrielle · UY 150 GS
UY 150 GS FG Chromium
UY 150 GS
FG
Chromium
3
Point style FG - Cloth point Medium ball point • Round point with medium ball • Suitable for loose-knit fabrics, elastic material and material containing rubber or elastane Coating Chromium Needle with standard chrome coating. Recommended for: Medium-weight woven fabrics, Leather for clothing, Artificial leather Examples of use: Jeans, Workwear, Suits, Accessories, Shoes, Leather clothing, Covers for upholstery
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 90/14 | 706122 | — | 100 pièces | 0.91 g |
| 100/16 | 706132 | 38.1 mm | 100 pièces | 0.916 g |
| 110/18 | 706142 | 38.1 mm | 100 pièces | 0.934 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Canu designation | 21:05 |
| Catalog designation | 339200BC04R |
| Further point designations | SUK |
| Further point designations 02 | B BALL |
| Further point designations 03 | M BALL |
| Further point designations 04 | SI |
| Further point designations 05 | BPM |
| Further point designations 06 | LAC |
| Further point designations 07 | R SUK |
| Further point designations 08 | U |
| Further point designations 09 | R KB |
| Technical sewing application | Double chain stitch |
| Stitch type class | 400 |
| Recommended for | Medium-weight woven fabrics, Leather for clothing, Artificial leather |
| Examples of use | Jeans, Workwear, Suits, Accessories, Shoes, Leather clothing, Covers for upholstery |
| Point style | FG - Cloth point |
| Needle system | UY 150 GS |
| Needle system family | UY 150 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | UOX 150 G |
| System designation 2 | UY 150 A |
| System designation 3 | UY 150 G |
| System designation 4 | UY 150 GA |
| System designation 5 | UY 150 GAS |
| System designation 6 | UY 151 GS |
| System designation 7 | 1373 |
| System designation 8 | SY 6780 |
| System designation 9 | SY 6781 |
