Aiguille industrielle · UY 163 GAS
UY 163 GAS R Chromium
UY 163 GAS
R
Chromium
6
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 65/9 | 707172 | 44 mm | 100 pièces | 1.04 g |
| 70/10 | 707182 | 44 mm | 100 pièces | 0.875 g |
| 75/11 | 707192 | 44 mm | 100 pièces | 0.875 g |
| 80/12 | 707202 | 44 mm | 100 pièces | 0.883 g |
| 90/14 | 707212 | 44 mm | 100 pièces | 0.817 g |
| 100/16 | 707222 | 44 mm | 100 pièces | 0.922 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 37.3 mm |
| Overall length | 44 mm |
| Shank length | 13.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 30:62 |
| Catalog designation | 373200AC01R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Stitch type class | 400 |
| Point style | R - Cloth point |
| Needle system | UY 163 GAS |
| Needle system family | UY 163 |
| Variant | GAS |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | UOX 163 |
| System designation 2 | UOX 163 GAS |
| System designation 3 | UY 163 GS |
| System designation 4 | MY 1242 |
| System designation 5 | 1619 |
| System designation 6 | SY 7185 |
| System designation 7 | UY 8021 |
| System designation 8 | UY 8021 GS |
