Aiguille industrielle · UY 163 GHS
UY 163 GHS FFG Chromium
UY 163 GHS
FFG
Chromium
3
Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 70/10 | 707142 | 44 mm | 100 pièces | 0.872 g |
| 80/12 | 707152 | 44 mm | 100 pièces | 0.883 g |
| 90/14 | 756872 | 44 mm | 100 pièces | 0.917 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 37.3 mm |
| Overall length | 44 mm |
| Shank length | 13.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | SES |
| Canu designation | 30:62 |
| Catalog designation | 373200AC01FFG |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Stitch type class | 400 |
| Point style | FFG - Cloth point |
| Needle system | UY 163 GHS |
| Needle system family | UY 163 |
| Variant | GHS |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | UOX 163 J |
| System designation 2 | UOX 163 GAS B |
| System designation 3 | UY 163 GBS |
| System designation 4 | MY 1242 SES |
| System designation 5 | 1619 SES |
| System designation 6 | SY 7186 |
| System designation 7 | UY 8021 GHS |
