Aiguille industrielle · UY 180 GVS
UY 180 GVS R Chromium
UY 180 GVS
R
Chromium
3
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Medium-weight woven fabrics, Leather for clothing, Artificial leather Examples of use: Jeans, Workwear, Suits, Accessories, Shoes, Leather clothing, Covers for upholstery
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 100/16 | 707332 | 38.6 mm | 100 pièces | 0.75 g |
| 110/18 | 707342 | 38.7 mm | 100 pièces | 0.802 g |
| 140/22 | 707362 | 39 mm | 100 pièces | 0.899 g |
Caractéristiques techniques
| Shank diameter | 1.82 mm |
|---|---|
| Length butt to eye | 34.1 mm |
| Shank length | 9.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 23:05 |
| Catalog designation | 341182AC03R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Point style | R - Cloth point |
| Needle system | UY 180 GVS |
| Needle system family | UY 180 |
| Variant | GVS |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | UYX 180 GVS |
| System designation 2 | SY 6937 |
