Aiguille industrielle · UY 180 GYS

UY 180 GYS R Chromium

SystèmeUY 180 GYS

PointeR

FinitionChromium

Tailles9

Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
80/12	707562	38.3 mm	100 pièces	0.8 g
90/14	707572	38.4 mm	100 pièces	0.713 g
100/16	707582	38.6 mm	100 pièces	0.855 g
110/18	707592	38.7 mm	100 pièces	0.855 g
120/19	707602	38.8 mm	100 pièces	0.853 g
125/20	707612	38.9 mm	100 pièces	0.851 g
130/21	760092	38.9 mm	100 pièces	0.889 g
140/22	707622	39 mm	100 pièces	0.923 g
150/	707632	39.2 mm	100 pièces	0.967 g

Caractéristiques techniques

Shank diameter	1.82 mm
Length butt to eye	34.1 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	R
Canu designation	23:05
Catalog designation	341182AC02R
Further point designations	SET
Further point designations 02	RD
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	R - Cloth point
Needle system	UY 180 GYS
Needle system family	UY 180
Variant	GYS
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	UOX 180 G
System designation 2	UY 180 GPS
System designation 3	UY 180 GS
System designation 4	UY 180 GYS
System designation 5	UY 185 GBS
System designation 6	SY 6935
