Aiguille industrielle · UY 506 GS
UY 506 GS S Chromium
UY 506 GS
S
Chromium
1
Point style S - Cutting point Cutting point • Cuts the leather in the sewing direction • Straight seam • Tight stitch formation with corresponding leather and stitch size • Stitch holes are elongated and clearly visible in the seam • Suitable for medium to large stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 110/18 | 708082 | 41.3 mm | 100 pièces | 0.93 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Needle size Asia | 18 |
| Length butt to eye | 36.6 mm |
| Overall length | 41.3 mm |
| Shank length | 13.5 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B – Straight needle with double groove |
| Canu point | S |
| Canu designation | 26:35 |
| Catalog designation | 366200BC02S |
| Further point designations | CR |
| Further point designations 02 | RSP |
| Further point designations 03 | NCR |
| Technical sewing application | Double chain stitch |
| Stitch type class | 400 |
| Recommended for | Thin leather |
| Examples of use | Leather clothing, Shoes, Accessories |
| Needle size | 110 Nm |
| Point style | S - Cutting point |
| Needle system | UY 506 GS |
| Needle system family | UY 506 |
| Variant | GS |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | UY 501 GS |
| System designation 2 | MY 1026 |
| System designation 3 | SY 7098 |
